Load Bearing: >20T(static)
Warranty: 18 Months
Body material: Heavy-duty casting aluminum
Power supply: The solar panel(monocrystalline 2.5V/0.2W)
Visual distance: ＞ 800m
Working Mode: Flashing or Constant
Waterproof: IP68
Aluminum Solar Cat Eyes Features:
•Up to 800 meters of visibility.
•Reliable all night, all-year-round performance.
•Totally sustainable harnessing free solar energy.
•Used where street lighting is either unavailable, Solar Cat Eyes not cost-effective or environmentally impossible.
•Cost-effective, LED Solar Cat Eyes are easy to install and require absolutely no wires or maintenance.
•Solar-powered Solar Cat Eyes self-contained surface mounted.
•Solar Cat Eyes for road accept OEM/ODM
LED Solar Cat Eyes for road Parameters:
| Material: | Heavy-duty casting aluminum |
| Power supply: | The solar panel(monocrystalline 2.5V/0.2W) |
| Battery: | NI-MH 1.2V/800MAH or lithium battery |
| Working model: | Blinking or Constant Charging at daytime and working automatically at night |
| LED: | 3pcs per side, total 6 pcs |
| LED colors: | Yellow, White, Red, Green, Blue |
| Life span: | 3 years |
| Resistance: | >20T(static) |
| Size: | 120*50mm(bottom) 4.72″*1.97″(bottom) 135*50mm(upper) 5.31″*1.97″(upper) |
| Visual distance: | >800M |
| Water poof: | IP68 |
| Carton Size: | 24pcs/ctn; weight: 17kgs; Carton size: 43*25*28CM/57*41*23.5CM 24pcs/ctn; weight: 37.48bs; Carton size: 16.92″*9.84″*11.02″/22.44*16.14″*9.25″ |
Application of Aluminum LED Solar Cat Eyes C1:
♥Schools and hospitals
♥Highways
♥High traffic areas
♥Walking paths
♥Transit stations
♥Parks and campuses
♥Urban Road
Installation Method Of Embedded Aluminum Solar Cat Eyes C1:
1. Carefully mark the distance between the placement of Solar Cat Eyes lights. To prevent an adverse effect on the ground, use a proper tool such as Core Drill. Drill Φ120mm and depth will be 50mm.
2. Remove all debris from the installation hole.
3. Pour epoxy into the holes per the manufacturer’s instruction.
4. Verity that the installation hole is straight. Verify that the installation hole is large enough to allow the epoxy to surround the led Solar Cat Eyes shaft.
5. Set the lighting surface of the Solar Cat Eyes to the desired viewing angle. Verify the epoxy is evenly adhering to the installation hole and Solar Cat Eyes shaft.
6. After curing the LED Solar Cat Eyes for 6-8 hours, remove the installation of the isolation facility.
